ETM 1004 T

Electric truck mixer

No emissions, no compromises. The new semi-trailers with electric drum drive offer full performance and availability.

— Technical data.

Nominal filling *                                  10 m³
Water capacity **                               11.05 m³
Geometric drum capacity                  17.64 m³
Assembly weight Standard ***         7,830 kg
Battery capacity                                  32 kWh
Operating voltage                               650 VDC

* Nominal filling in compacted mixed concrete.

** Measured in accordance with DIN 459-1 at min. 2 drum rotations per minute. The given values for capacity and water volume only apply to a horizontally aligned mixer frame. A deflection of the frame during loading is not taken into account here and may negatively affect the water volume under certain circumstances. The real maximum filling capacity with concrete depends on the consistency and the rheological characteristics of the concrete. The topology of the road and the driveability also influence the maximum loading volume.

*** Weight details for basic unit with chassis power take-off (PTO), incl. 2 extension chutes, compl. assembled/ready for operation, deviations +/- 5%.
